Lc Cold Joint Fabrication
3M LC Series Cold Shrink Joints provide a quick, reliable, and tool-free solution for low-voltage cable jointing up to 3.3kV.
Overview
The LC Series Cold Shrink Joints are designed for multi-core low-voltage power cables up to 1.9/3.3kV, including XLPE/PVC insulated, steel wire armored (SWA), and PVC sheathed cables, with or without a lead sheath . They are suitable for flexible or trailing cables, cable tray applications, and indoor installations. For direct burial, additional mechanical protection may be required .
Key Features
- Cold Shrink Technology: Eliminates the need for resin, heat, or special tools, allowing for fast and reliable installation .
- Environmental Protection: The outer cold shrink tube provides a robust seal resistant to acids, alkalis, ozone, and UV light .
- Compatibility: Works with copper or aluminum conductors, multi-core cables (1.5–300 sqmm), and single-core cables (50–1000 sqmm), including marine and offshore EPR insulated cables .
- Shelf Life: Tubes and insulation tapes have a 5-year shelf life when stored at 10–27°C and <75% relative humidity .
Installation Advantages
- Tool-Free: No heat guns, torches, or adhesives are required, reducing installation risk and time .
- Compact Design: Smooth profile allows installation in confined spaces, such as manholes or cable trays .
- Active Memory Seal: The tubing maintains its shape and adhesive capability during temperature fluctuations and load swings, ensuring long-term reliability .
Applications
- Indoor and outdoor low-voltage power distribution
- Emergency lighting, fire pump systems, and control systems
- Marine and offshore installations
- Cable repair, extension, or connection
Summary
The LC Cold Shrink Joints are a safe, efficient, and durable solution for low-voltage cable jointing. Their cold shrink technology simplifies installation, reduces the need for specialized tools, and provides excellent environmental protection, making them ideal for both standard and challenging installation environments .
